Description

According to the EN 81 standard

a system has been designed for hydraulic and traction elevators with up to 16 stops. This system is compatible with various control systems. The temperature value is continuously monitored, and in exceptional situations, the system is automatically checked. Safety measures include menu password protection and a Personal Unlocking Key (PUK) code to prevent unauthorized use. Additionally, after maintenance, the system can be locked, and there is both digital system control and extra mechanical system monitoring.

Each stop can be assigned a unique alphanumeric floor name, and the system retains the last 99 errors in memory, allowing for retrospective fault tracking. Short-circuit-protected digital and signal outputs are also part of the system. Furthermore, by using Ekvator HTR for serial communication between two lines, cost savings can be achieved in terms of cable and labor expenses. There’s even a connector card that simplifies connections when using flat cables.
